DRILLING MACHINE

Home > Products > METAL > DRILLING MACHINE
TB 20 T - 400 V

Order No.:
Stock:
Delivery Time:

Without Tax: $
Machine video:

QUICK OVERVIEW

The TB 20 T is a cost efficient table drilling machine with V-belt drive available with 230 V or 400 V. This model comes complete with right and left turning device. The great price to performance ratio makes this model an attractive choice for hobby craf

Contact us

TECHNICAL SPECIFICATIONS

Drilling capacity max.

20 mm

Drill chuck

1 - 16 mm / B 16

Morse taper

MT 2

Spindle speed

(16) 180 - 2770 rpm

Distance spindle to column

180 mm

Drilling table tiltable

-45° to +45°

Distance spindle to table max.

415 mm

Distance spindle to base

605 mm

Spindle stroke

80 mm

Column diameter

72 mm

Table size / T-slot size

290 x 290 mm / 16 mm

Work surface base

205 x 205 mm

Motor power output S1 100%

0,55 kW / 400 V

Motor power input S6 40%

0,80 kW / 400 V

Machine dimension (W x D x H)

380 x 620 x 1000 mm

Weight approx.

54 kg

FEATURES

  • High-quality ball bearings ensure high spindle concentricity
  • Large drill table features diagonal T-slots
  • Drill table tilts (±45°), height adjustment via gear rack
  • Rotation switch for right and left turn
  • Powerful, high-torque aluminium motor according to IP 54 standard
  • High grade keyless drill chuck comes standard
  • Treated machine base allows clamping of oversize workpieces
  • Features T-slots on polished base
  • Ergonomical handles allow for high work comfort



Standard accessories:

  • Keyless drill chuck 1 - 16 mm / B 16
  • Drill chuck arbor MT 2 / B 16
  • Height adjustable protective cover
  • Separate emergency stop switch
  • Left and right turning
  • T-slot nuts
  • Tools



Optional accessories:

  • Drilling machine vise BM 125 (Art.Nr.:28-2000)
  • 19 pcs. set TiN-coated HSS drills, 1-10 mm (Art.Nr.:41-1000)
  • 25 pcs. set TiN-coated HSS drills, 1-13 mm (Art.Nr.:41-1010)
  • 50 pcs. set TiN-coated HSS drills, 1-5,9 mm (Art.Nr.:41-1015)
  • 130 pcs. set TiN-coated HSS drills (Art.Nr.:41-1024)
  • 170 pcs. set TiN-coated HSS drills (Art.Nr.:41-1025)
