ROTARY TABLES

BS-3

Order No.:
Stock:
Delivery Time:

Without Tax: $
Machine video:

QUICK OVERVIEW

FEATURES: ◆The BS-3 is designed and made according to characteristics and advantages to all kinds of divid-ing heads,suitable for general dividing,gear and rack spindle cutting,in many use. ◆Designed for super hole 55.5mm of diameter,shaft hole.Slope of end hole is Morse’s taper No.6 and the Bs-3can be adjused from being level or vertical(0°-90°)。 ◆All the BS-3’s shaft,spindle center,worm and gear are made of super steels through grinding,heat treatment,to achieve rigid construction. ◆Its tailstock designed in dovetail joint,very strong in structure which is available for heavy-duty load,also the degree can be adjusted in every direction. ◆The ratio of worm and worm gear is 1:40 ◆The Dividing plate is availtable in two sides.A and B.A Face 24.25.28.30.34.37.39.41.42.43.B Face 46.47.49.51.53.54.57.58.59.62.66. ◆The changable gears are 24.28.32.38.40.44.48.56.64.72.86 and 100. ◆Standard accessories are:Center,Carrier Gear Bracket.Gear Set. ◆Center Height of Tail Stock
