| ITEMS | Unit | FK15110A | FK15125A | FK15145 |
| center height | mm | 110 | 125 | 145 |
| diameter of the table surface | mm | Φ125 | Φ160 | Φ160 |
| T-slot width on table surface | mm | 10H12 | 10H10 | 10H10 |
| Worm gear radio | 1:90 | 1:90 | 1:90 | |
| diameter of center bushing | mm | Φ16H7 | Φ20H7 | Φ20H7 |
| diameter of indexer tram bushing | mm | / | / | / |
| Width of locating key | mm | 14 | 18 | 18 |
| Connecting dimensions of spindle nose | mm | Φ52H6 | A16 | A16 |
| Collet | / | / | / | |
| Motor | N.m | ≥ 2.94 | ≥ 2.94 | ≥ 2.94 |
| Air pressure | Pa | 4~6×105Pa | 4~6×105Pa | 4~6×105Pa |
| Repeatability | 7.5" | 7.5" | 7.5" | |
| Dividing accuracy | 60" | 60" | 60" | |
| Max. tangent torque | N.m | 90 | 120 | 120 |
| Max.speed | r/min | 11.1 | 11.1 | 11.1 |
| Net Weight | kg | 50 | 80 | 90 |
| Gross Weight | kg | 58 | 88 | 100 |
| Load capacity 水平Horizontal | kg | 100 | 150 | 150 |
| 垂直Vertical | 50 | 80 | 80 |
