| Model | mm | DM-48A |
| Table Area | mm | 1220x2440 |
| Traveling Area | m/min | 1320x2540x250 |
| Traveling Speed | m/min | 40 |
| Working Speed | kw | 15 |
| Spindle Power | r/min | 9.0 |
| Spindle Speed | rpm | 2400 |
| Working Voltage | AC380V/3PH/50HZ | |
| Driving System | Delta/Yaskawa | |
| Controller | Syntec/NC-studio | |
| Tool magazine | Linear/Carousel | |
| Locate Mode | Positioned in three points by portable high precision positioning cylinder(2 in X Axis＋1 in Y Axis) | |
| Table structure | Vacuum |
Optional：
Automatic loading& unloading system/safety protection guard/drilling/double staion/B Axis/C Axis/C Axis/Aggregate head/vacuum cup/Partition table/Vacuum pump/Hold-down device,etc.
