| Model | Unit | ZX5150A |
| Table size | mm | 1500x320 |
| Table travel | mm | 900x400X500 |
| Max. Workpiece weight | kg | 500 |
| T-solts(No./width/pitch) | 3/8/110 | |
| Max. Vertical milling DIA. | mm | 32 |
| Spindle taper | NT40 | |
| Spindle speed/range | rpm | 95~2250(16steeps |
| Distance between spindle end and bench | mm | 120~520 |
| Distance between spindle axis and guidway | mm | 500 |
| Main motor | kw | 1.5/2.4 |
| Pump power | w | 90 |
| Contral systerm | ||
| Net weight | kg | 2200 |
| Machine size | mm | 1800x1700x2200 |
