| Specification | Unit | X6128A | X6128C |
| Table size | mm | 1200×280 | 1200×280 |
| Table travel(X Y Z) | mm | 620/260/360 | 620/260/360 |
| Spindle speed range | r/min | 45-1350(12steps) | 45-1350(12steps) |
| Spindle taper | ISO40 | ISO40 | |
| Table feed(X Y) | mm/min | 13-265 (8steps) | 30-855 (8steps) |
| Table feed(Z) | mm/min | Mannua 手动 | 9-270 (8steps) |
| Distance between horizontal spindle and ram surface | mm | 150 | 150 |
| Distance between horizontal spindle and table surface | mm | 135~535 | 110~510 |
| Main motor power | kw | 3 | 3 |
| Overall size | mm | 1750×1450×1750 | 1750×1450×1750 |
| Net weight | kg | 1350 | 1380 |
