| Specificatio | Unit | X7140 | X7140S |
| Table size | mm | 1700X400 | 1700x400 |
| T-slots(NO./width/pitch) | mm | 3/18/110 | 3/18/110 |
| Longitudinal travel | mm | 1300 | 1300 |
| Cross travel | mm | 420 | 420 |
| Vertical travel | mm | 500 | 500 |
| Distance between spindle and table surface | m/min | 100-600 | 100-600 |
| Table rapid feed speed(X) | m/min | 8 | 8 |
| Table rapid feed speed(Y) | m/min | 8 | 8 |
| Table rapid feed speed(Z) | - | 6 | 6 |
| Spindle hole taper | mm | BT40 | NT50 |
| Stroke of soindle quil | mm/rev | - | - |
| Spindle speed range | HP | 8000/6000 | 125-1500 |
| Main motor power | N.m | 5.5/7.5kw | 7.5 |
| Distance from spindle center to column rail surface | kg | 500 | 500 |
| Overall size (LxWxH) | 2600x2200x2300 | 2600x2200x2300 | |
| Net weight | 3800 | 3800 |
