| Specification | Unit | SM6235 | SM6235A | SM6235B | SM6235C |
| Table size | mm | 1270X300 | 1370X300 | 1270X300 | 1370X300 |
| Table Travel (X/Y/Z) | mm | 720/300/400 | 820/300/400 | 900/380/400 | 1000/380/400 |
| Rapid feed speed X/Y/Z | mm/min | 1335/1335/1000 | |||
| Spindle taper | 3HP:R8 or ISO30;5HP:ISO40 | ||||
| Table feed (X/Y/Z) | mm/min | XY:30-830 Z:23-625 | |||
| T-slots(NO./Width/Pitch) | mm | 3/14/80 | |||
| Arm travel | mm | 450 | |||
| Main motor Power | kw | 3HP/5HP | |||
| Torque of X/Y/Z axis AC servo motor | N.m | 10 | |||
| Spindle speed range | ram | 80-4200(Variable) / 65-4660(16steps) | |||
| Overall size | mm | 1720X1680X23500 | 1820X1680X2350 | 1720X1680X23500 | 1820X1680X23500 |
| Net weight | kg | 1650 | 1700 | 1700 | 1750 |
