VERTICAL MACHIN CENTER

Home > Products > METAL >  MACHINING CENTER > VERTICAL MACHIN CENTER
VMC400

Order No.:
Stock:
Delivery Time:

Without Tax: $
Machine video:

QUICK OVERVIEW



Contact us
Specification VMC400/500
Table dimension 800x450 мм/1000x500MM
Max table load 400 KG/500KGr
T-slot 3*18*90
Max tool diameter (Adjacent without tool) 80MM/130 MM
Distance from spindle nose to table 120 - 620 мм/105 - 655MM
Travel of X/Y/Z 600/500/500
Raoid traverse rate of X/Y/Z 36/36/30
Distance from spindle center line to column guide 550 /595MM
Spindle speed 8000 r/min
Type of tool shank/rivet BT 40
Tool storage capacity 24 Disc type.
Tool changing time 2.0 (tool to tool)
Positioning accuracy ± 0.005 mm / 300
Repeated positioning accuracy ± 0.003 mm
Spindle motor power(a motor torque106N.m) 5.5/7.5 кw/ 7.5/11кw
Overall dimensions 2.4x2.14x2.8 м/2.7x2.1x2.9 M
Net weight 4200 кг/5500кг
