| Specifications | unit | TCK420 |
| max. swing over bed | mm | 420 mm |
| max. swing over cross slide | mm | 270mm |
| max. processing length | mm | 400mm |
| X/Z axis travel | mm | 160/400 mm |
| spindle nose | mm | A2-6 |
| spindle bore | mm | 66 |
| spindle drawing pipe diameter | mm | 50 |
| max. spindle speed | rpm | 3000 |
| chuck | inch | 8 |
| spindle motor power | kw | 5.5 |
| X/Z axis position accuracy | mm | 0.016/0.002mm |
| X/Z axis repeatability | mm | 0.006/0.006mm |
| X/Z axis feed motor torque | N.m | 5/7.5 |
| X/Z axis feed motor power | kw | 1.3/1.88 |
| X/Z rapid feed speed | m/min | 12 |
| tailstock travel | mm | 350 |
| tailstock sleeve diameter | mm | 90 |
| tailstock taper | MT4# | |
| tool post type | 8 station hydraulic magazine | |
| cutting tool shape size | mm | 20*20 |
| guide way type | Linear guideay | |
| total power capacity | kva | 11 |
| machine dimension | mm | 2300*1500*1650 |
| N.W. | kg | 3000 |
