| Specifications | MJ760 | |
| control | SIEMENS 802 D | |
| max. turning diameter over bed | 760 mm | |
| max. turning diameter over support | 580 mm | |
| max. workpiece diameter | 560 mm | |
| max. workpiece length | 7,801,500 | |
| main motor rating | AC 22 / 30 kW | |
| spindle | speeds | 7-680,27-2000 rpm |
| bore in spindle | 105 mm | |
| spindle torque | 1096 (Low speed) | |
| spindle nose ISO | A2 - 11 | |
| travel | X | 315 mm |
| Z | 855,1555, | |
| rapid feed | X | 12 m/min |
| Z | 15 m/min | |
| hydraulic jaw chuck diameter | 381 mm | |
| number of tool stations | 10 | |
| tool shank size | 32 x 32 mm | |
| boring bar size Ø | 50 mm | |
| tool changer | 1.0 sec | |
| quill diameter | 120 mm | |
| quill stock | 100 mm | |
| tailstock taper | MT 4 | |
| dimensions L x W x H | 4630 x 1825 x 2270 mm | |
| net weight | 8500,8800, kg | |
