CZK40 CNC LATHE FOR YOKE
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video:
QUICK OVERVIEW
Contact us
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video:
QUICK OVERVIEW
Contact us
| Model | CZK40 | CZK50 |
| 1.Worktable size LxW | 480mm×250mm | 400mm×350mm |
| number of T groove / space | 3/80 (according to user require) | 3/100 (according to user require) |
| 2. spindle | 2,4 or 6 Spindles | 2,4 or 6 Spindles |
| spindle speed range | 300-1800mm/min | 300-3000mm/min |
| spindle taper | BT40 | BT40 |
| Max. travel of X axis | 230mm | 400mm |
| Max. travel of Z axis | 230mm | 200mm |
| Max. travel of Y axis | 200mm | 200mm |
| feeding speed | 50-6000mm/min | 10-1000mm/min |
| fast speed | 2000-8000mm/min | 2000-6000mm/min |
| Max. distance from spindle centerline to worktable | 135mm | 280mm |
| 3. motor total capacity | ||
| spindle motor | Y100L-4 3kW 1440mm/min | Y132M-6 4KW or Y132S-4 5.5KW |
| X/Y axis servo motor | 130SM1015 | 130SM15015 or 130BYG3501 |
| Z axis servo motor | 110SM04030 | 110SM04030 |
| cooling pump | AB-25 90W 2800mm/min | AB-25 90W 2800mm/min |
| 4.machine dimensions (L×W×H) | 2000mm×1010mm×1585mm | 2400mm×1500mm×1670mm |
| 5. net weight of the machine | 2460kg | 4000kg |
