CM6241
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video:
QUICK OVERVIEW
CM6241 /Features: Precision ground and hardened bedways The spindle is supported with precision roller bearings Head stock gears are made of high quality steel ground and hardened Completed style of change gear cover
Contact us
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video:
QUICK OVERVIEW
CM6241 /Features: Precision ground and hardened bedways The spindle is supported with precision roller bearings Head stock gears are made of high quality steel ground and hardened Completed style of change gear cover
Contact us
| Model No. | CM6241 |
| CM6241V | |
| Centers Distance | 1000/1500 мм |
| Swing over Bed | 410 мм |
| Swing Over Cross Slide | 255 мм |
| Max. swing over gap | 580 мм |
| Bed width | 210 мм |
| Range of spindle speed | (16)45 - 1800 rpm 30 - 550/550-3000 rpm |
| Spindle bore | 52 мм |
| Spindle nose | D1-6 |
| Taper of spindle bore | MK 5 |
| Range of cross feeds X | 0.025 - 0.85 мм/rev |
| Range of longitudinal feeds Z | 0.05 - 1.7 мм/rev |
| Range of metric threads | (39) 0.2-14 mm |
| Range of inch threads | (45) 2-72 TPI |
| Tailstocd sleeve DIA | 50 мм |
| Taper of tail stock quill | MK 4 |
| Max. travel of tailstock quill | 120 мм |
| Power of motor | 2.2 kw |
| Votaga | 400 V |
| Packing Size | 2.06/2.56x0.9x1.64 м |
| Weight(N/G) | 1300/1600 kg |
| Standard accessories | Special accessories |
| Three jaw chuck | Coolant system |
| Four jaw chuck | Brake |
| Steady rest | Driving plate |
| Follow rest | Living center |
| Face plate | Taper turning attachment |
| Dead center | Drill chuck |
| Thread chasing dial | Stopper |
| Chip tray | QCTP |
| Splash guard | DRO |
| Toolbox & tools 1set | Chuck cover |
| Lead screw cover |
