| Specification | VL850 |
| Table dimension | 1000x500MM |
| Max table load | 700KG |
| T-slot | 3 /5-18*80 |
| Distance from spindle nose to table | 15 - 670 MM |
| Travel of X/Y/Z | 800*500*520 MM |
| Raoid traverse rate of X/Y/Z | 36*36*30 MM |
| Distance from spindle center line to column guide | 565MM |
| Spindle speed | 8000 об/мин |
| Type of tool shank/rivet | BT 40 |
| Tool storage capacity | 24 шт. |
| Tool changing time | 1.8сек |
| Max tool diameter (Adjacent without tool) | 80/125 MM |
| Positioning accuracy | ± 0.010 mm / 300 |
| Repeated positioning accuracy | ± 0.005 mm |
| Spindle motor power(a motor torque106N.m) | 11/15кВт |
| Overall dimensions | 2.95x2.2x2.75 M |
| Net weight | 5200KG |
