SPECIFICATION:
| Item | Unit | CBD20 |
| Capacity | kg | 2000 |
| Load Centre | mm | 600 |
| Wheel Base | mm | 1354 |
| Drive Wheel | mm | Φ252 x 78 |
| Balance Wheel | mm | Φ80 x 60 |
| Balance Wheel Distance | mm | 500 |
| Front Wheel | mm | Φ80 70 |
| Front Gauge | mm | 378/523 |
| Lifting Height | mm | 115 |
| Handle Height | mm | 1280/1180 |
| Min.Fork Height | mm | 85 |
| Overall Length | mm | 1733 |
| Case Length | mm | 583 |
| Overall Width | mm | 720 |
| Fork Width | mm | 540/685 |
| Fork Size | H/W/L | 60x160x1150 |
| Ground Clearance | mm | 25 |
| Turning Radius | mm | 1545 |
| Travel Speed | km/h | 4-5 |
| Lifting Speed | mm/s | (27-35)Load/Unload |
| Descent Speed | mm/s | (42-37) Load/Unload |
| Max.Gradient performance | % | 6 |
| Drive Motor Rating | kw | 0.75 |
| Lifting Motor Rating | kw | 0.8 |
| Battery | V/Ah | 24/210 |
| Battery Weight | kg | 160 |
| Type of Driving | Pedestrian/Stand |
