QUICK OVERVIEW
The MSB 320 HGL metal bandsaw is equipped with a saw frame swinging up to 60° for mitre cutting. The stepless speed adjustment and the automatic blade break control ensure user-friendly and safe operating.
Contact us
SPECIFICATION
|
Cutting capacity round / flat 90° |
320 mm / 610 x 320 mm |
|
Cutting capacity square 90° |
320 x 320 mm |
|
Cutting capacity round / flat 75° |
320 mm / 580 x 320 mm |
|
Cutting capacity square 75° |
320 x 320 mm |
|
Cutting capacity round / flat 60° |
320 mm / 510 x 320 mm |
|
Cutting capacity square 60° |
320 x 320 mm |
|
Cutting capacity round / flat 45° |
320 mm / 355 x 320 mm |
|
Cutting capacity square 45° |
320 x 320 mm |
|
Cutting capacity round 30° |
260 mm |
|
Cutting capacity flat 30° |
280 x 200 mm |
|
Working height |
740 mm |
|
Bandsaw blade dimensions |
4160 x 27 x 0,9 mm |
|
Cutting speed, stepless |
20 - 100 m/min |
|
Coolant pump |
120 W |
|
Motor power |
1,5 kW |
|
Machine dimensions (L x D x H) |
2100 x 1200 x 1340 mm |
|
Weight approx. |
1000 kg |
FEATURE
- Ideal for cutting of profiles, pipes, full rivet iron and non-ferrous materials
- This model features enhanced cutting capacity
- Automatic blade break control stops the machine if blade breaks
- Variable cutting speed for convenient operating
- Automatic, height adjustable lifting of the saw frame at cutting end with adjustable lift height
- Saw frame tilts up to 60° for mitre cutting
- Optimal cutting results due to the stepless speed adjustment
- Automatic shut-down at cutting end
- Stable saw frame, thereby smooth and vibration-free run
- Torsion-free, strong saw frame for precise cutting
Standard accessories:
- Bandsaw blade
- Material fence
- Manometer for blade tension
- Quick clamping vice
- Coolant device
- Hydraulic cylinder
- Motor protective switch
- Automatic blade break control
- Automatic shut-down
- Roller table
Optional accessories:
- Bandsaw blade 4160 x 27 x 0,9 4/6 TpI
- Bandsaw blade 4160 x 34 x 0,9 4/6 TpI
- Micro cooling system
- Hydraulic blade tensioning
- Hydraulic vice
- Sensitive press control
- Hydraulic top clamping
- Roller table RB 4 - 1000
- Roller table RB 7 - 2000
- Roller table RB 10 - 3000
- Measurement system LS 1 for RB 4 - 1000
- Measurement system LS 2 for RB 7 - 2000
- Measurement system LS 3 for RB 10 - 3000
- PVC - rolls set for RB 4 / 7 / 10 / 13 (3 pcs.)
- Universal coolant fluid RK 12, 5 l canister
