QUICK OVERVIEW
The Z5180 is suitable for drilling, reaming and tapping of single parts or small series. The solid, grey cast iron construction makes this machine suitable for heavy machining in engineering, production and construction.
Contact us
TECHNICAL SPECIFICATIONS
|
Drilling capacity in steel |
80 mm |
|
Thread cutting max. |
M56 |
|
Torque |
800 Nm |
|
Travel of drill head |
260 mm |
|
Morse taper |
MT 6 |
|
Spindle speed / steps |
40 - 570 rpm, 9 steps |
|
Feed range |
(6) 0,1 - 0,78 mm/rev. |
|
Feeding force |
30000 N |
|
Distance spindle to column |
375 mm |
|
Distance spindle to table max. |
810 mm |
|
Spindle stroke |
250 mm |
|
Table size / T-slot size |
660 x 555 mm / 22 mm |
|
Table lift |
300 mm |
|
Motor power |
5,5 kW |
|
Machine dimension (W x D x H) |
900 x 1300 x 2850 mm |
|
Weight approx. |
2500 kg |
FEATURES
- Solid construction of column and base designed for excessive use
- Powerful drive motor features high torque and large feed force
- Solid grey cast iron construction maximizes table load capacity
- Tapping device comes with automatic change of rotation at adjusted drill depth
- Convenient control lever allows for quick and easy feed and speed adjustment
- Polished gear wheel, in oil bath, ensure smooth operartion
- Automatic spindle feed, tapping device and work lamp included in standard equipment
- Includes feed motor for rapid and work feed and back stroke
- Wide, heavy-duty dovetail guidings feature adjustable gibs
Standard accessories:
- Coolant device
- Thread cutting device
- Left and right turning
- LED working light
- Morse taper drill sleeve
- Tools
- Height adjustable protective cover
Optional accessories:
- Two-parts milling vise 200
- Drilling machine vise 200
- Machine mount 120
