FOUR MAST ALUMINUM LIFT

Home > Products > TRANSPORT > ALUMINUM ALLOY LIFT TABLE > FOUR MAST ALUMINUM LIFT
SJL0.3-16（four-Mast)

Order No.:
Stock: 1-10
Delivery Time: 30

Without Tax: $
Machine video: 4000-6000

QUICK OVERVIEW

Aluminum alloy aerial working platform adopts high strength aluminum molding material. The series of products have four types for customers to choose, such as single-mast, double-mast, treble-mast or four-mast. It is suitable for workshops, guesthouses, mansions, department stores, stations, airports and stadiums, etc.

Contact us
Model Dimension Platform Load Capacity Weight (kg)
(mm) (mm) (kg)
SJL0.1-4(single) 1100*850*1980 600*600 100 370kg
SJL0.1-6(single) 1200*850*1980 600*600 100 380kg
SJL0.1-8(single) 1300*850*1980 600*600 100 430kg
SJL 0.1-10(single) 1400*850*1980 600*600 100 540kg
SJL 0.2-6(double) 1300*900*1980 1200*600 200 550kg
SJL 0.2-8(double) 1400*900*1980 1200*600 200 580kg
SJL 0.2-10(double) 1900*1000*1980 1500*600 200 630kg
SJL 0.2-12(double) 2000*1000*1980 1550*600 200 730kg
SJ 0.2-14(double) 2000*1000*2280 1600*600 200 940kg
SJL 0.2-16 (double) 3000*1500*2200 1500*600 200 1400kg
SJL 0.3-16(four) 2500*1300*2400 1800*850 300 1650kg
SJL 0.3-18(four) 2500*1300*3000 1800*850 300 2000kg
SJL 0.3-20(four) 3000*1500*2200 1500*600 300 2200kg
Features: 1) High strength aluminum molding material keeps deflecting degree and swing tiny. 2) Equipped with overload safety protection device 3) Equipped with safeguard valve to avoid hydraulic pipe rupture 4) It installs the emergency manual hydraulic valve to cope with power cut. 5) It also can add stretch platform to extend to the desired place when the platform length isn’t enough. 6) Double chains greatly improve the safety factor. 7) Adopt emergency stop button multiple safety protection measures. 8) The translatable supporting legs can ensure working dead zone minimization. 9) Tailor-made guide wheel device equipped on the mast makes lifting smooth and stable.
