SJL 0.3-20(four)
Order No.:
Stock: 1-10
Delivery Time: 30
Without Tax: $
Machine video: 5000-6000
QUICK OVERVIEW
Aluminum alloy aerial working platform adopts high strength aluminum molding material. The series of products have four types for customers to choose, such as single-mast, double-mast, treble-mast or four-mast. It is suitable for workshops, guesthouses, mansions, department stores, stations, airports and stadiums, etc.
Contact us
Order No.:
Stock: 1-10
Delivery Time: 30
Without Tax: $
Machine video: 5000-6000
QUICK OVERVIEW
Aluminum alloy aerial working platform adopts high strength aluminum molding material. The series of products have four types for customers to choose, such as single-mast, double-mast, treble-mast or four-mast. It is suitable for workshops, guesthouses, mansions, department stores, stations, airports and stadiums, etc.
Contact us
| Model | Dimension | Platform | Load Capacity | Weight (kg) |
| (mm) | (mm) | (kg) | ||
| SJL0.1-4(single) | 1100*850*1980 | 600*600 | 100 | 370kg |
| SJL0.1-6(single) | 1200*850*1980 | 600*600 | 100 | 380kg |
| SJL0.1-8(single) | 1300*850*1980 | 600*600 | 100 | 430kg |
| SJL 0.1-10(single) | 1400*850*1980 | 600*600 | 100 | 540kg |
| SJL 0.2-6(double) | 1300*900*1980 | 1200*600 | 200 | 550kg |
| SJL 0.2-8(double) | 1400*900*1980 | 1200*600 | 200 | 580kg |
| SJL 0.2-10(double) | 1900*1000*1980 | 1500*600 | 200 | 630kg |
| SJL 0.2-12(double) | 2000*1000*1980 | 1550*600 | 200 | 730kg |
| SJ 0.2-14(double) | 2000*1000*2280 | 1600*600 | 200 | 940kg |
| SJL 0.2-16 (double) | 3000*1500*2200 | 1500*600 | 200 | 1400kg |
| SJL 0.3-16(four) | 2500*1300*2400 | 1800*850 | 300 | 1650kg |
| SJL 0.3-18(four) | 2500*1300*3000 | 1800*850 | 300 | 2000kg |
| SJL 0.3-20(four) | 3000*1500*2200 | 1500*600 | 300 | 2200kg |
| Safety Features |
| -Explosions proof valves, which protect the hydraulic pipe and prevent rupture |
| -Spillover valve, which prevents high pressure when the lift rises |
| -Emergency decline valve, which smoothly lowers the lift in case of an emergency |
| After-sale service： |
| A. We offer 12 month warranty apart from artificial faults, during warranty time, we will bear the cost of parts and freight. |
| B. If it is necessary for you, our engineer are available to service machinery overseas. |
| C. We offer 24 hours service for technical support and any assistance. |
| 1.Travel switch: The lifter will stop automatically when touch it. |
| 2. Control panel: control button on platform; control box on ground, which enable user operate lift more freely. |
| 3. Outrigger: guarantee stability of whole machine when work. |
| 4. Hydraulic power unit: Lisheng brand, long time service life. |
| 5. Aluminum alloy profile: make whole machine with light weight. |
| 6. Double chains: Keep safe. |
| 7. Locking key switch on control distributor |
| 8. Auxiliary platform lowered device: User can push this button to make lift fall down when meet an emergency. |
| 9. Polyurethane wheel: no damage to the ground floor, suitable for work indoor. |
