HYDRAULIC LOADING RAMP

Home > Products > TRANSPORT > HYDRAULIC LOADING RAMP
LRL4-7

Order No.:
Stock: 1-10
Delivery Time: 30-60

Without Tax: $
Machine video: 8000-16000

QUICK OVERVIEW

Wall mounted lift for goods - This wall mounted lift is typically used to transport goods or pallets between floors of buildings. - It can easily be used indoors or outdoors in buildings, warehouses, or wherever you need it! - It provides efficient, convenient, and safe access to mezzanines, basements, or any level of a multi-storied building.

Contact us
Model LRL4-7
Platform Size 3500-4500mm
Platform 8mm Checkered Steel Plate reinforced by 20# steel channel.
Pump Station 11kw
Load Capacity 4000kg
Voltage 415V,50hz, or according to your local voltage
Stops 2
Lifting Height 7000mm
Seal Ring Japanese Valqua Seal.
Cylinder 120/160mm*2pcs
Lead Rail                                        100*100*7mm rectangular tube with 4 post
The Product
This wall mounted lift is perfect for moving materials, products, or supplies from one level to another. It’s a highly customizable product, and the lifting capacity, platform size, and dimensions are all things that can be provided exactly to your specifications.
Besides a powerful hydraulic lifting system, this freight elevator includes extremely accurate controls, allowing you to stop at any location. It also features a high load capacity and extra safety characteristics, like sensitive overload protection and locking protection.
This lift also has the benefit of a lower operating cost – it has a low failure rate, due to its progressiveand safe hydraulic system with effective control mode, and low power consumption, because the lift uses power relative to how much weight it is carrying to conserve energy.
It is widely used in factories, warehouses, industrial plants, and anywhere else that requires a safe,
reliable, and affordable freight elevator.
