DRO DN300

Order No.:
Stock: 30
Delivery Time: 30

Without Tax: $
Machine video: 129-169

QUICK OVERVIEW

DN300 is the Digital Read Out System suitable for most of the metal cutting machine applications. It is a popular DRO for Milling machines and Lathe machines. DN300 DRO has silicon keyboard with tactile keys which gives long life for key board and reliable operations. DN300 DRO has USB communication port to transfer the data to or from computer. The machine tool probe can be connected to this DRO.

Contact us
SPECIFICATIONS:
Feature Details
No. Axes 2 Axis/3 Axis
Display 0.56" LED 7 Segment
Case Plastic Injection moulded
Power 90...265 VAC (50/60 Hz)
Temperature -20°C to +70°C /-4°F to +158°F
Operating Temperature 0°C to +50°C / 32°F to +122°F
Relative Humidity 20% to 85% Non-condensing Dimensions
Dimensions (HxWxD) 155mm x 270mm x 80mm
USB Service Port Fitted as standard
Auxiliary Port Optional
