DRO DN400
Order No.:
Stock: 30
Delivery Time: 30
Without Tax: $
Machine video: 139-179
QUICK OVERVIEW
Product Description: DN400 is the Digital Read Out System suitable for most of the metal cutting machine applications. It is a popular DRO for Milling machines and Lathe machines. DN400 DRO has silicon keyboard with tactile keys which gives long life for key board and reliable operations. DN400 DRO has USB communication port to transfer the data to or from computer. The machine tool probe can be connected to this DRO.
Contact us
Order No.:
Stock: 30
Delivery Time: 30
Without Tax: $
Machine video: 139-179
QUICK OVERVIEW
Product Description: DN400 is the Digital Read Out System suitable for most of the metal cutting machine applications. It is a popular DRO for Milling machines and Lathe machines. DN400 DRO has silicon keyboard with tactile keys which gives long life for key board and reliable operations. DN400 DRO has USB communication port to transfer the data to or from computer. The machine tool probe can be connected to this DRO.
Contact us
| SPECIFICATIONS: | |
| Feature | Details |
| No. Axes | 2 Axis/3 Axis |
| Display | 0.56" LED 7 Segment |
| Case | Plastic Injection moulded |
| Power | 90...265 VAC (50/60 Hz) |
| Temperature | -20°C to +70°C /-4°F to +158°F |
| Operating Temperature | 0°C to +50°C / 32°F to +122°F |
| Relative Humidity | 20% to 85% Non-condensing Dimensions |
| Dimensions (HxWxD) | 155mm x 270mm x 80mm |
| USB Service Port | Fitted as standard |
| Auxiliary Port | Optional |
