C46K
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video: https://www.youtube.com/watch?v=TKZG0TYaXec
QUICK OVERVIEW
Integrated slant bed structure.easy liquid leaking, high rigidity and good operation. High speed at 5000r/min. First-class precision spindle bearing. High precision ball screw, fast feeding for high working efficiency. All-closed stainless steel protection, strong liquid protection without any water leak. 8 position hydraulic turret with 2,4,6 or 8 living tools.
Contact us
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video: https://www.youtube.com/watch?v=TKZG0TYaXec
QUICK OVERVIEW
Integrated slant bed structure.easy liquid leaking, high rigidity and good operation. High speed at 5000r/min. First-class precision spindle bearing. High precision ball screw, fast feeding for high working efficiency. All-closed stainless steel protection, strong liquid protection without any water leak. 8 position hydraulic turret with 2,4,6 or 8 living tools.
Contact us
| Configuration/Type | UNIT | C46K with CE | |||
| Maximum Swing Over Bed | mm | 400 | |||
| Maximum Swing Over Slide | mm | 140 | |||
| Maximum Machining Length | Collet | mm | 385 | ||
| Chuck | mm | 380 | |||
| Spindle Head Type | GB59001 | A2-5 | |||
| Spindle Taper Hole | ø/mm | 52 | |||
| Maximum Diameter of Bore | Manual Chuck | ø/mm | |||
| Hydraulic Through Chuck | ø/mm | 38 | |||
| Hydraulic Collet | ø/mm | 48 | |||
| Spindle Speed Range | r/min | 60-5000 | |||
| Spindle Shift Mode | servo | ||||
| Spindle Rated Torque | Nm | 35 | |||
| Main Motor Power | Kw | 5.5 | |||
| Spindle Motor Maximum Speed Range(30 Min) | Kw | 7.5 | |||
| Chuck Type | Hydraulic Through or None ThroughChuck | ||||
| Chuck Size | Inch | 6” | |||
| Rapid Traverse Speed On X/Z -axis | m/min | 25/75 | |||
| Servo Motor Torque On X/Z-axis | Nm | 7.5/75 | |||
| X/Z -axis Travel | mm | 400/460 | |||
| Ball Screw | X-axis | mm | Oct-32 | ||
| Diameter / Thread | Z-axis | Oct-32 | |||
| Guideway Type | PMI(Taiwan) Linear Guideway | ||||
| Linear Guideway width X/Z -axis | mm | 30/30 | |||
| Turret Type | Gang Type | ||||
| Turning Tools /Boring Bar Size | mm | 20*20 / ø 25 | |||
| Dimension / Weight | L*W*H(mm) | 2220*1780*1955 / 2500KG | |||
| Optional Configuration | |||||
| Hydraulic Through Chuck | 6” | ||||
| Torque Electric 8 Tool Post (PRAGATI) | |||||
| Chips Conveyor | Hinge-Belt | ||||
