ZX45
Order No.:
Stock: 10
Delivery Time: 30
Without Tax: $
Machine video: 1000-1200
QUICK OVERVIEW
Contact us
Order No.:
Stock: 10
Delivery Time: 30
Without Tax: $
Machine video: 1000-1200
QUICK OVERVIEW
Contact us
| Model | ZX45 | |
| Max.drilling capacity(iron/steel) | mm | 31.5/40 |
| Max.mill capacity(face/end) | mm | 80/32 |
| Spindle taper | MT3/MT4/R8/ISO30 | |
| Worktable size | mm | 800*240 |
| Worktable travelX/Y | mm | 570/230 |
| Head tilt left right | mm | 90 |
| Spindle travel | mm | 130 |
| Spindle nose to worktable | mm | 470 |
| Spindle center to column surface | mm | 285 |
| Spindle speed(option) | rmp | 6steps:60Hz 90~197050Hz 75~1600rmp |
| Motor(option) | kw | 1.1 |
| N.W/G.W | KG | 300/350 |
| Packing size(L*W*H,enclude foot and pan) | mm | 850*760*1150 |
| 20’container | sets | 30 |
