ZX 7045S
Order No.:
Stock: 10
Delivery Time: 30
Without Tax: $
Machine video: 2500-3000
QUICK OVERVIEW
Contact us
Order No.:
Stock: 10
Delivery Time: 30
Without Tax: $
Machine video: 2500-3000
QUICK OVERVIEW
Contact us
| Model | Unit | BFB45 Profis |
| Max.drilling capacity(iron/steel) | mm | 31.5/45mm |
| Max.mill capacity(face/end) | mm | 80/32mm |
| Spindle taper | MT3/MT4/R8/ISO30 | |
| Worktable size | mm | 800×240mm |
| Worktable travelX/Y | mm | 500/230mm |
| Head tilt left right | 90° | |
| Spindle travel | mm | 130mm |
| Spindle nose to worktable | mm | 470mm |
| Spindle center to column surface | mm | 285mm |
| Spindle speeds range(2 steps) | r/min | 12steps:75-3200 |
| motor | kw | 0.85/1.1kw |
| N．W/G.W | KG | 300/350KG |
| Packing size(L×W×H) | mm | 1140×960×2240mm |
| 20’Container | sets | 12 |
| Standard Accessories: |
| Draw bar,Adapter,Taper shank for drilling chuck , |
| Drilling chuck ,Arbor ,T slot bolt ,Washer ,Nut , |
| Tilted wedge ,Spanner ,Oil gun |
|
|
| Optional: |
| Cooling system,Working light,Spindle power |
| down feeder,DRO,depth indicator,spring collet, |
| vices,milling collet ,milling clamp. |
