JY290-F
Order No.:
Stock: 20
Delivery Time: 30
Without Tax: $
Machine video: 2300
QUICK OVERVIEW
JY-290-F Benchtop Metal Lathe sports generous capacity, a lot of thread ranges, a wider bed, and a larger chuck, With features like a 1" spindle bore, 3/4"–12 TPI leadscrew and an MT#3 tailstock, you'll be able to turn some surprisingly hefty projects!
Contact us
Order No.:
Stock: 20
Delivery Time: 30
Without Tax: $
Machine video: 2300
QUICK OVERVIEW
JY-290-F Benchtop Metal Lathe sports generous capacity, a lot of thread ranges, a wider bed, and a larger chuck, With features like a 1" spindle bore, 3/4"–12 TPI leadscrew and an MT#3 tailstock, you'll be able to turn some surprisingly hefty projects!
Contact us
| Model | JY290-F | JY300A | JY320 | JY330A |
| JY290V-F | ||||
| Distance | 700mm | 750/914mm | 600mm/750mm | 550mm/750mm |
| between centers | ||||
| Swing over bed | 280mm | 300mm | 320mm | 330mm |
| Swing over cross slide | 165mm | 180mm | 200mm | 210mm |
| Width of bed | 180mm | 181mm | 200mm | 160mm |
| Taper of spindle bore | MT5 | MT5 | MT45 | MT45 |
| Spindle bore | 38mm | 38mm | 38mm | 38mm |
| Number of spindle speeds | 6/variable speed | 9 | 12 | 12 |
| Range of spindle speeds | 125-2000/50-2000rpm | 75-14rpm | 60-1600rpm | 60-1650rpm |
| Range of longitudinal feeds | 0.07 -0.4mm /r | 0.018-0.238mm /r | 0.1 -1.4mm /r | 0.018-0.275mm /r |
| Range of inch threads | 8-56T.P.I | 2-1/2-40T.P.I | 2.5-48T.P.I | 20/40~9T.P.I |
| Range of metric threads | 0.2-3.5mm | 0.45-10mm | 0.2 -3.5mm | 0.5-4mm |
| Top slide travel | 50mm | 76mm | 100mm | 100mm |
| Cross slide travel | 140mm | 175mm | 160mm | 160mm |
| Tailstock quill travel | 80mm | 90mm | 80mm | 70mm |
| Taper of tailstock quill | MT3 | MT3 | MT3 | MT23 |
| Motor | 750/1100W | 1100W | 750W | 1100W |
| Packing size | 1400 × 700 × 680mm | 1730/1960x750x1450mm | 1470 × 770× 1470mm | 1720/1550x770x750mm |
| Net weight | 230kg | 480kg/ 550kg | 450kg/ 390kg | 260kg/ 300kg |
