QUICK OVERVIEW
The small EBS 100 B metal bandsaw allows mitre cuts to one side and features an electronically adjustable speed change, making this model ideal for cutting of various materials.
Contact us
Order No.:
Stock: 5
Delivery Time: 30
Without Tax: $
Machine video: 1-999
QUICK OVERVIEW
The small EBS 100 B metal bandsaw allows mitre cuts to one side and features an electronically adjustable speed change, making this model ideal for cutting of various materials.
Contact us
TECHNICAL SPECIFICATIONS
|
Cutting capacity round 90° |
100 mm |
|
Cutting capacity flat 90° |
100 x 100 mm |
|
Cutting capacity round 45° |
60 mm |
|
Cutting capacity flat 45° |
55 x 60 mm |
|
Bandsaw blade dimensions |
1140 x 13 x 0,65 mm |
|
Cutting speed, stepless |
20 - 70 m/min |
|
Motor power |
1,5 kW |
|
Voltage |
230 V |
|
Machine dimensions (L x D x H) |
550 x 340 x 400 mm |
|
Weight approx. |
16 kg |
FEATURES
- Ideal for cutting of profiles, tubes, solid iron workpieces, non-steel materials, wood
- Ideal on construction sites and for installation work
- Light weight allows for easy transportation
- Stepless speed adjustment: 20 - 70 m/min
- Machine body and saw frame made of high-quality aluminium die casting
- Powerful motor, even at continuous operation
- Smooth, vibration-free running due to high quality aluminium drive wheel
- Ball bearing bandsaw blade guide with quick adjustment
- Adjustable fence for series production
Standard accessories:
- Bandsaw blade
- Workpiece fence
- Stepless speed adjustment
Optional accessories:
- Bandsaw blade HSS 1140 x 13 x 0,65 - 14 TpI (Art.Nr.:47-1000)
- Bandsaw blade HSS 1140 x 13 x 0,65 - 8 TpI (Art.Nr.:47-1001)
- Bandsaw blade BiFlex 1140 x 13 x 0,65 - 14 TpI (Art.Nr.:47-1002P)
- Bandsaw blade BiFlex 1140 x 13 x 0,6 - Vario 6/10 TpI (Art.Nr.:47-1004)
